Sonik 70R 54mm Rebated Door
The Sonik 70R represents the next level in sound attenuation, featuring Komfort’s 54mm rebated acoustic glazed door.
By incorporating a rebated frame design, this system provides a superior seal and flush finish, delivering enhanced acoustic performance of up to 42dB (Rw). Like the rest of the Sonik range, it is designed for seamless integration across all Komfort partitioning systems, prioritising both ease of installation and long-term maintenance.
The Sonik 70R manufactured doorset is available in single, hospital, or double configurations. Whether specified with lift-off hinges or an offset pivot and floor spring, it is the ideal solution for environments where acoustic privacy is paramount, without compromising on sleek, glazed aesthetics.
Key Features.
01.
Acoustics up to 42dB (Rw) – UKAS accredited laboratory in accordance with BS EN ISO 10140
02.
70mm frame for flush design preferences and enhanced performance
03.
Fully compatible with our Polar partitioning range
04.
Maximum height of 3000mm and maximum width of 1100mm
05.
Compatible with electronic access options
06.
Allows for deflection heads
Compatibility
- Kross Glazed Bars
- Automated Door Systems
- Access Control
- Blinds
- Switch Glass
Technical Information
Complete Range
Explore and compare our Sonik door range to identify the specialist system that seamlessly aligns with your creative vision, while meeting your specific acoustic and structural compliance responsibilities.
Current Product
Sonik 70R
Enhanced sound attenuation, featuring Komfort’s 54mm rebated acoustic glazed door.
ACOUSTICS
up to 42 dB (Rw)
PROFILE DIMENSIONS
70x54mm
DIMENSIONS (WxH)
1100x3000mm
Current Product
Sonik 52
44mm Acoustic glazed door, meticulously designed for a minimalist aesthetic and effortless integration.
ACOUSTICS
up to 37 dB (Rw)
PROFILE DIMENSIONS
52x44mm
DIMENSIONS (WxH)
1100x3000mm
Current Product
Sonik 70
44mm Acoustic glazed door range, featuring a 70mm frame depth for enhanced presence and performance.
ACOUSTICS
up to 40 dB (Rw)
PROFILE DIMENSIONS
70x44mm
DIMENSIONS (WxH)
1100x3000mm
Current Product
Sonik 70S
28mm Sliding acoustic glazed door, available in both offset and pocket configurations.
ACOUSTICS
up to 35 dB (Rw)
PROFILE DIMENSIONS
70x28mm
DIMENSIONS (WxH)
1300x3000mm
