Komfort Soteria Fire Screens

Soteria is our advanced slimline EI Fire Screen system named after the Greek goddess of safety and salvation, deliverance and preservation from harm. Soteria embodies these principles, offering exceptional fire protection within a sleek, minimalist design.

Performance Overview
Komfort’s Soteria Fire Screens provide both integrity and insulation, effectively stopping flames, flammable gases, and heat transfer. This system features a slimline steel frame and offers fire ratings from 30 to 90 minutes for integrity and insulation, alongside acoustic performance up to 42dB (Re). It seamlessly integrates into various designs while delivering robust fire protection. The system can also include unlatched single or double doors with ratings up to EI60.

Why Choose Soteria?

  • Slimline Design: Complements our Polar partitioning sightline for a cohesive aesthetic

  • Glass-to-Glass Corner Joints: Available for 30 and 60-minute fire ratings

  • Our fire compliant specifications meet the requirements of Approved Document M1 volume 2

  • EN Standards Tested: Independently verified for superior performance

  • Versatile Butt Joints: Choose from translucent, black, white and other colors to suit your design

  • Wide, Mullion-Free Lengths: Create uninterrupted visual expanses

Applications

  • Fire Escape Routes

  • Reception Areas

  • Lift Areas & Staircases

  • Atriums

Soteria Glazed Fire Screens at a Glance

Dimensions:
Screen Height up to 3.0m*
Module Width up to 1.4m*
Framework Depth 55-69mm*
Door Leaf Height up to 2.9m*
Door Leaf Width up to 1.0m*

Fire performance:
Screens up to 90 minutes Integrity and Insulation*
Doors up to 60 minutes Integrity and Insulation
In accordance with EN 1634-1, EN 1364-1 & EN 15725:2023

Acoustics:

Glazed Screens up to 42dB (Rw)*
Speech Privacy Potential up to ‘Good’*

Structure:
Up to 1.5kN/m to BS 6180:2011

Door options:
Full Height Single & Double Unlatched Doors*

Glazing Options:
Single Glazed EI30-EI90 Glass

Compatible with:

  • Integral Blinds

  • Manifestations

  • Graphics

  • SwitchGlass

  • Kross Glaze

Paint / finishes:

  • Polyester powder coat

  • Physical Vapor Deposition Finish

  • Stainless Steel Finish

Register to our ‘Fire Rated Systems and Safety for a Commercial Space’ RIBA accredited CPD

Through video demonstrations, diagrams and real-life examples, this CPD seminar will help specifiers design with fire safety in mind for a commercial setting; introducing fire terminology, regulations, classifications, testing process and more. Exploring the performance, applications and building design considerations for fire rated glazed partitioning and doors, fire screens and fire rated timber doors. Fire safety is an absolute priority when designing buildings and this seminar will provide you with a good understanding of the key factors when specifying fire rated partitioning and screens.
