Komfort Soteria XL Fire Screens

Soteria XL is our advanced EI Fire Screen system named after the Greek goddess of safety and salvation, deliverance and preservation from harm. Soteria XL can reach greater heights and offers enhanced structural performance when comparing with our Soteria system, as well as deflection at the head.

Performance Overview
Komfort’s Soteria XL Fire Screens provide both integrity and insulation, effectively stopping flames, flammable gases, and heat transfer. This system features a slimline steel frame and offers fire ratings from 30 to 60 minutes for integrity and insulation, alongside acoustic performance up to 41dB (Rw). It seamlessly integrates into various designs while delivering robust fire protection. The system can also include unlatched single or double doors with ratings up to EI60.

Why Choose Soteria?

  • Heights of up to 4.15m: Ideal for larger openings

  • Compatible with automated door systems: Wider design options

  • Deflection Head: Allowing for movement

  • Glass-to-Glass Corner Joints: Available for 30 and 60-minute fire ratings

  • Our fire compliant specifications meet the requirements of Approved Document M1 volume 2

  • EN Standards Tested: Independently verified for superior performance

  • Versatile Butt Joints: Choose from translucent, black, white and other colors to suit your design

  • Wide, Mullion-Free Lengths: Create uninterrupted visual expanses

Applications

  • Fire Escape Routes

  • Large Atriums

  • Reception Areas

  • Lift Areas & Staircases

Soteria Glazed Fire Screens at a Glance

Dimensions:
Screen Height up to 4.15m*
Module Width up to 1.4m*
Framework Depth 60mm*
Door Leaf Height up to 2.9m*
Door Leaf Width up to 1.0m*

Fire performance:
Screens up to 60 minutes Integrity and Insulation*
Doors up to 60 minutes Integrity and Insulation
In accordance with EN 1634-1, EN 1364-1 & EN 15725:2023

Acoustics:

Glazed Screens up to 41dB (Rw)*
Speech Privacy Potential up to ‘Good’*

Structure:
Up to 1.5kN/m to BS 6180:2011

Door options:
Single & Double Unlatched Doors*

Glazing Options:
Single Glazed EI30-EI60 Glass

Compatible with:

  • Integral Blinds

  • Manifestations

  • Graphics

  • SwitchGlass

  • Kross Glaze

Paint / finishes:

  • Polyester powder coat

  • Physical Vapor Deposition Finish

  • Stainless Steel Finish
